Specially designed for chemically sensitive plastic parts, and for leak detection, SKL-4C is a red dye visible penetrant that is water based and water washable. As with most plastic parts, it is recommended that a trial application be used to confirm compatibility. Indications appear dark purple-red in visible light and fluorescent orange in ultraviolet light. This allows dual range flexibility in the inspection process. SKL-4C can be diluted with water, although it is recommended that a dilution ratio of 1:1 is used for general purposes.
Benefits
- Water based
- Can be used for leak detection
- Can be used in visible and UV light inspections
Applications
Defect location: open to surface
Ideal for:
- Ceramic components
- Leak testing
- Chemically sensitive plastic components (test plastic compatibility before use)
Use Recommendations
NDT Method: Penetrant Testing, Leak Testing
Type: Type 2
Methods: Method A or Method C
Temperature Range: 40 to 125°F / 4 to 52°C
